Forum + exhibition, layout of 3C electronics, rail transportation and other 6 major fields
In the field of electronic manufacturing, as small as capacitors, connectors and other components, as large as mobile phone keyboards, PC motherboards, hard disks, machine vision system can be seen in almost every link of the chain of the electronic manufacturing industry. As a big manufacturing country, China concentrates 70% of the world's 3C product capacity. As one of the most important pillar industries, 3C electronics industry has undoubtedly become a key market for machine vision application projects.
Image: Application of machine vision in the electronics industry
This year, the Beijing Machine Vision Assisted Intelligent Manufacturing Innovation and Development Conference will be held in Beijing International Convention Center on June 24-25, 2021. The conference in the form of BBS + exhibition, the "machine Vision technology exhibition" create innovative technology solutions communication circles present Vision technology, Plus + 6 major application fields include: rail transport, solar energy, electronic information, biological medicine, aerospace, agricultural equipment in key areas such as communication interactive innovation technology, the application examples of on-site experience.
Vision Plus+ electronic information
This article has collected some innovative application cases and new technologies of machine vision in the field of electronics for you. The following brands will be displayed in the program exhibition area of the conference. Let's follow the Xiaobian to have a look!
Baomeng Electronics (Shanghai) Co., Ltd
Baomeng LX series 10,000MB network interface camera
Applications: 3C electronics, electronic assembly, electrical engineering/semiconductor/robotics, automation/rail transit, railway, intelligent transportation
#New technology of
The Bolmeng-LX series 10,000MB network interface camera can reliably detect minute details and deviations, which is very suitable for applications requiring high resolution and image quality. At the same time, the new models have higher frame rates and faster image transfers. The camera with Sony Pregius S sensors has a frame rate of up to 50fps and a resolution of up to 24 megapixels. The camera with the GPixel sensor even has a resolution of 65 megapixels and a frame rate of 18fps. This has been a boon for applications such as PCB, display or semiconductor inspection, as well as 3D measurement technology and product tracking. Also, with their rugged design and rich features, they are ideal for demanding outdoor applications such as sports or rail transit.
Keens (China) Co., Ltd
2D/3D line laser profilometer LJ-X8000 series
Application: 3C electronics, electronic assembly, electrical engineering
# Innovative application solutions
This product performs well in 3C electronics, electronic assembly, and electrical engineering applications. Its fully upgraded 3D line laser profilometer LJ-X8000 series uses microscope-level lens and ultra-high precision CMOS. Each profile is composed of 3200 points, with a maximum repetition accuracy of 0.3um. We provide a wide range of measuring heads ranging from 7mm to 720mm, to deal with a wide variety of detection scenarios, and provide point cloud data for customers to secondary development, to achieve a win-win situation.
Other fields are applied in solar energy/rail transit, railway, intelligent transportation/precision engineering and optics.
Hangzhou Haikang Robot Technology Co., Ltd
ID2000 series high speed focus type industrial reader
Applications: 3C electronics, auto parts, food and drug packaging, logistics
# Innovative application solutions
Products in 3C electronics, electronic assembly, electrical engineering applications in the field of outstanding performance. Its structure is compact and light, and can focus at high speed within 5ms. It can identify labels and DPM codes efficiently and effectively. It has high-speed solid-state focusing lens technology, and can quickly adjust the focus within 5ms. The product size is 46mmx25mmx40mm, with two installation methods of side and back, which can be perfectly embedded into automatic machines and equipment.
Other fields are used in food and drug packaging, logistics and other fields.
Shanghai Tuyang Information Technology Co., Ltd
Percipio FS820
Applications: 3C electronics, electronic assembly, electrical engineering/robotics, automation
# Innovative application solutions
In the fields of 3C electronics, electronic assembly, and electrical engineering applications, the industrial 3D camera developed and produced based on proprietary binocular structured light technology is designed for use with cooperative robots. The fuselage and structure of this product are in line with high quality industrial standards. Invisible infrared light source, no need for additional lighting. Logistics stable design, factory calibration without correction, maintenance-free; The integrated hardware ISP supports high quality 2M pixel RGB images and supports 2D image algorithms and deep learning requirements. And all the image processing and depth engines are built into the local FPGA chipset, using the form of embedded vision processor, without the need for the client host computing resources. At the same time, it can be used in automation and other fields.
Xi 'an Zhi Micro Sensing Technology Co., Ltd
DKAM130 Series 3D Camera
Application fields: 3C electronics, electronic assembly, electrical engineering (key fields)/robotics, automation/monitoring, security/military defense
#New technology of
Products in 3C electronics, electronic assembly, electrical engineering applications with advanced technology - RGB point cloud fusion function, the use of micro sensing development and mass production of the latest generation of MEMS micro vibration mirror chip, with higher power laser light source, built-in computing platform, to achieve higher accuracy, wider field of vision, greater depth of field, stronger robustness. It can directly output point cloud, RGB, gray scale, depth map to users, without occupying user's computing resources. It supports GIGE protocol, and provides perfect multi-platform SDK, and supports Halcon and other visual software to help users develop quickly. At the same time can be applied to automation, national security and other fields.
Hongke Electronic Technology Co., Ltd
IRID IDS integrated reasoning camera
Applications: 3C electronics, electronic assembly, electrical engineering (key field)/biomedicine (key field)/semiconductor/robotics, automation
# New technology/innovative applications
The product combines cutting-edge technologies in 3C electronics, electronic assembly, and electrical engineering applications, making it possible to solve tasks that reach the limits of traditional, rules-based image processing. With NXT Ocean, an easy-to-use all-in-one key technology solution, anyone -- even with no programming experience -- can create a fully autonomous inference camera that can perform completely independent machine vision tasks. With the help of NXT Lighthouse, a cloud-based software, even non-professionals with no knowledge of AI can train an AI classifier from their own image data and immediately execute it on an NXT camera. The user only needs to know the images and estimates. This product not only develops the training software of neural network, but also develops the powerful AI core for NXT camera. Implement neural network hardware accelerated FPGA technology. With the NXT Ocean Design Suite, customers will get all the necessary components to start implementing their AI applications immediately. This makes it particularly easy to get into deep learning-based image processing. At the same time, it can be used in biomedicine, semiconductor, automation and other fields.
Shenzhen North China Industrial Holding Co., Ltd
BIS-6665A30
Application fields: 3C electronics, electronic assembly, electrical engineering (key fields)/rail transit, railway, intelligent transportation (key fields)/robotics, automation/packaging/printing
# New technology/innovative applications
BIS-6665A30 is a multi-network port embedded quasi-system based on Intel B75 chip set created by North China Industrial Control Co., Ltd. The products support Intel I3/I5/I7 second and third generation processors, LGA1155 CPU; Provide two vertical SODIMM, support DDR3-1333/1600, maximum capacity Up to 16G Bytes; Multi-serial port design, provide standard 7PIN SATA3.0 interface, VGA+HDMI display interface; Multi-network port design, support Gigabit Ethernet/WiFi /3G/4G network, support RS232/RS485/RS422 communication, with flexible network application environment, support 8-channel isolated DIO interface, support LPC extension 32-channel isolated DIO interface, support hardware and software call starting function, the system is stable and reliable.
